Top-brand compressor
Intelligent control variable speed motor
Hydrophilic fin type heat exchanger / high-efficient plate heat exchanger
Two series for different application ambient temperature
Hot water supply / heating
Top-brand compressor
Intelligent control variable speed motor
Hydrophilic fin type heat exchanger / high-efficient plate heat exchanger
Two series for different application ambient temperature
Hot water supply / heating
Model | KRS-100E/N2-M | KRS-200E/SN2-M | KRS-300E/SN2-M | KRS-380E/SN2-M | KRS-450E/SN2-M | ||
Power supply | Ph-V-Hz | 220V/1PH/50HZ | 380V/3PH/50HZ | ||||
Working temp | ℃ | -15℃~43℃ | -15℃~43℃ | -15℃~43℃ | -15℃~43℃ | -15℃~43℃ | |
Max. outlet Water temp. | ℃ | 60℃ | 60℃ | 60℃ | 60℃ | 60℃ | |
Water Heating (A20/W55) | Capacity | KW | 10.5 | 19 | 30 | 38 | 45 |
Hot water yield | L/h | 226 | 408 | 645 | 817 | 967 | |
Input | KW | 2.55 | 4.55 | 7.2 | 9.2 | 10.8 | |
COP | W/W | 4.12 | 4.18 | 4.17 | 4.13 | 4.17 | |
Rated current | A | 12.46 | 7.83 | 12 | 15.84 | 18.6 | |
Max. input consumption | KW | 3.57 | 6.37 | 10.08 | 12.88 | 16.2 | |
Max. input current | A | 17.45 | 10.97 | 18.36 | 22.18 | 27.89 | |
Water system | materials of water pipe | copper | copper | copper | copper | copper | |
water flow | m3/h | 2.3 | 4.1 | 6.4 | 8 | 10 | |
Water different pressure | Kpa | 40 | 50 | 55 | 55 | 55 | |
Dia. water inlet pipe | mm | DN25 | DN25 | DN40 | DN40 | DN40 | |
Dia. water outlet pipe | mm | DN25 | DN25 | DN40 | DN40 | DN40 | |
Design pressure | Mpa | 4.2/0.02 | 4.2/0.02 | 4.2/0.02 | 4.2/0.02 | 4.2/0.02 | |
Outdoor noise level (1 meter) | dB(A) | 55 | 57 | 58 | 60 | 61 | |
Outdoor unit | Dimension(L*W*H) | mm | 752*690*765 | 752*690*965 | 1450*702*950 | 1450*702*1060 | 1450*702*1260 |
Packing(L*W*H) | mm | 840*750*900 | 840*750*1100 | 1525*805*1110 | 1525*805*1220 | 1525*805*1420 | |
NG/WG | kg | 87/103 | 119/137 | 236/279 | 249/294 | 268/316 | |
Warranty Terms | NOTE | 1% free spare parts provided for maintenance(min order 20ft container, but mix less than 3 models, less than min order, no free spare parts provided). | |||||
▲Testing condition: ambient Dry/Wet Bulb Temp.: 20℃/15℃; Water Inlet/Outlet Temp.: 15℃/55℃. |
