R32 refrigerant, less GWP than R410A, environmental friendly
Anti-UV ABS casing
Reliable performance with multi-protections
Titanium heat exchanger, corrosion resistant
Integrated controller with WiFi smart control
Heating, Cooling and Auto function included.
GMCC compressor, twin-rotary and DC inverter technology
R32 refrigerant, less GWP than R410A, environmental friendly
Anti-UV ABS casing
Reliable performance with multi-protections
Titanium heat exchanger, corrosion resistant
Integrated controller with WiFi smart control
Heating, Cooling and Auto function included.
GMCC compressor, twin-rotary and DC inverter technology
Model | LPRY-7I/Bp | LPRY-10I/Bp | LPRY-12I/Bp | LPRY-14I/Bp | LPRY-20I/Bp | ||
Ambiancy 28°C/Humidity 80%,Water 28°C | |||||||
Boost Mode | Heating capacity | W | 7,200 | 9,700 | 11,300 | 14,400 | 19,400 |
COP | - | 6.5-5.5 | 6.4-5.4 | 6.8-5.7 | 6.4-5.3 | 6.4-5.4 | |
Smart Mode | Heating capacity | W | 7,200-2900 | 9,700-3,400 | 11,300-3,950 | 14,400-5,300 | 19,400-6,800 |
COP | - | 11.0-5.5 | 10.8-5.4 | 11.1-5.7 | 10.8-5.3 | 11.4-5.4 | |
Eco Mode | Heating capacity | W | 4,800-2,900 | 6,400-3,400 | 7,350-3,950 | 9,500-5,300 | 12,600-6,800 |
COP | - | 11.0-8.5 | 10.8-8.4 | 11.1-8.6 | 10.8-8.4 | 11.4-8.7 | |
Ambiancy 15°C/Humidity 70%,Water 26°C | |||||||
Boost Mode | Heating capacity | W | 5,900 | 8,200 | 10,100 | 11,900 | 14,100 |
COP | - | 5.0-4.5 | 4.9-4.4 | 5.2-4.6 | 5.0-4.5 | 5.1-4.6 | |
Smart Mode | Heating capacity | 5,900-2,200 | 8,200-3,000 | 10,100-3,800 | 11,900-4,200 | 14,100-5,000 | |
COP | 6.8-4.5 | 6.7-4.4 | 6.9-4.6 | 6.8-4.5 | 6.9-4.6 | ||
Eco Mode | Heating capacity | 5,900-4,100 | 8,200-5,400 | 10,100-6,600 | 11,900-7,700 | 14,100-9,100 | |
COP | 6.8-5.5 | 6.7-5.4 | 6.9-5.6 | 6.8-5.5 | 6.9-5.6 | ||
Ambiancy 35°C/Humidity 54%,Water 27°C | |||||||
Boost Mode | Cooling Capacity | W | 3,500 | 5,100 | 6,350 | 7,150 | 8,500 |
COP | 3.02-2.62 | 2.95-2.60 | 3.04-2.65 | 3.0-2.60 | 3.0-2.60 | ||
Compressor | Brand | Panasonic | Panasonic | Panasonic | Panasonic | Panasonic | |
Refrigerant | Type | - | R32 | ||||
Quantity | g | 600 | 700 | 1,000 | 1,200 | 1,400 | |
Noise level | 1 m | dB(A) | 39-50 | 40-51 | 41-52 | 42-53 | 45-56 |
10 m | dB(A) | 20-30 | 21-31 | 22-34 | 22-35 | 25-36 | |
Water | flow | m3/h | 2-4 | 2-4 | 4-6 | 4-6 | 6-8 |
Max pressure | bar | 3 | 3 | 3 | 3 | 3 | |
connections | - | G1.5" / PVC 50 mm | |||||
Power supply | - | 230V / 1~ / 50 Hz | |||||
Nominal intensity | A | 4.5 | 5.5 | 7.0 | 9.0 | 11.0 | |
Maximum intensity | A | 7.0 | 8.2 | 10.5 | 11.5 | 15.0 | |
Dimentions (L x W x H) | mm | 936 x 322x 567 | 936 x 322x 567 | 1006x 342 x 625 | 1006x 342 x 625 | 1025 x 413 x 752 | |
Packing | mm | 1045 x 400 x 700 | 1045 x 400 x 700 | 1120x 420x 755 | 1120x 420x 755 | 1140 x 490 x 880 | |
Net weight | kg | 42 | 46 | 53 | 59 | 68 | |
Gross weight | kg | 53 | 57 | 64 | 70 | 83 |
