80℃ V-Form DC Inverter Heat Pump Water Heater for Industrial Process
R410a DC Inverter Heat Pump Water Heater for Industrial Process are engineered with advanced V-form heat exchangers and EVI technology for distillery, dyeing and food processing applications. Linuo Ritter delivers 80°C high-temp output with 2.5 COP efficiency and smart cloud-based monitoring to minimize energy costs.
1.V-Form Heat Exchanger Design
2.DC Inverter Technology (1Hz variable frequency)
3.80°C High-Temperature Output
4.Intelligent Defrosting Technology
5.Cloud-Based Smart Control 6.15-Year Service Life (electronic expansion valves, pressure sensors)
Optimized wind field with 25% larger heat exchange area
1Hz variable frequency, -20°C to +43°C operation range
20% faster defrosting than traditional methods
Cloud-based remote monitoring via 7-inch color screen
| Model | NT-AS-56FGBW | NT-AS-110FGBW | |
| Nominal operating conditions （A20W80） | Heating capacity (kW) | 56 | 110 |
| Input power (kW) | 22.4 | 47.8 | |
| COP | 2.5 | 2.3 | |
| electric current (A) | 38 | 83.7 | |
| Maximum input power (kW) | 38.5 | 73.5 | |
| Maximum current (A) | 61.8 | 126.5 | |
| Power type | 380V/3N～/50Hz | 380V/3N～/50Hz | |
| Rated outlet water temperature (℃) | 80 | 80 | |
| Maximum outlet temperature (℃) | 85 | 85 | |
| Noise dB (A) | 71 | 74 | |
| Categories of Protection against Electric Shock | I | I | |
| Protection class | IPX4 | IPX4 | |
| Refrigerant | R410a/R134a | R410a/R134a | |
| Filling amount (kg) | 7.0*2/4.2*2 | 14*2/13.6*2 | |
| Water side resistance (kPa) | ≤50 | ≤60 | |
| Loop connection size | DN65*2 | DN65*2 | |
| Dimensions（L*W*H）mm | 2180*1270*2070 | 2432*1330*2220 | |
| Packaging dimensions（L*W*H）mm | 2180*1310*2170 | 2482*1370*2320 | |
| Gross weight kg | 1000 | 1500 | |
| Applicable temperature range (℃) | -30~43 | -30~43 | |
High-Temp Heat Pump Description
We supply high-temperature heat pumps reaching 80°C output with DC inverter technology and V-form design. Ideal for factory bulk orders in food processing and dyeing industries, this industrial heat pump manufacturer solution cuts energy costs by 60% via smart cloud control and EVI compressor technology.
Application
| Industry | Application | Benefit | |
| Distillery | Steam generation, mash heating | Replaces gas boilers, 2.8-year payback | |
| Dyeing Factory | Hot water for fabric processing | 75°C stable output, 0.8-year payback | |
| Food Processing | Sterilization, cleaning | Eco-friendly R410a refrigerant | |
| Slaughterhouse | Meat processing hot water | 770kW system, 3-year ROI | |
